- 14 -

MAINTENANCE & SERVICE

Carefully reinstall burner, and make sure that:

The end of the burner ts into the slot on the

burner bracket.

The slots are centered under the ue tube.

The thermocouple is positioned properly (tip of

thermocouple extends over two slots of burner).

The color of the ﬂame is clear blue over the slots

of the burner.

12.

Clear blue color

of flame

If you run into a problem, refer to the troubleshooting table below.

TROUBLESHOOTING

Reconnect the wire to high voltage electrode. Check

the electrode for proper location and gap.

Turn on manual gas shutoff valve and check all t-

tings for leaks with soapy water.

RM2510: Connect 120 V power cord to the outlet

and reconnect/turn on the 12 V DC power.

Check LP gas safety shutoff.

13.

14.

15.

16.

Electrode

Burner tube

1/8” to 3/16

(3-5 mm)

Symptom Check/Remedial action

Refrigerator or freezer is not

cold enough

Is the plug rmly connected to the socket? Is there a power failure?

Is the thermostat properly set?

Is the refrigerator level? (Because of its operation it is important to keep an

absorption refrigerator level.)

Heavy frost build-up on evaporator ns? To prevent frost buildup, which can reduce

efciency, do not leave the unit’s door open longer than necessary.

Has the overheating protection been triggered or not? (Must be checked by an authorized

service technician.)

Has the door been closed properly? If not it can cause the inside temperature to rise.

Overpacked refrigerator? The unit will have to work harder if the refrigerator is stuffed

and results in higher cabinet temperatures. Arrange the food in the unit to allow for free

air circulation.

•

Odors from fumes Dislocated burner

Damaged burner

Dirty ue tube

•

The refrigerator does not work in

gas operation mode.

Gas bottle empty?

Air in the gas pipe?

Is the burner dirty, damaged or not properly located under the ue tube?

Is the burner jet clogged?

Is the ue bafe inserted properly in the ue tube?

Is the LP gas pressure low at burner?

Set the main regulator to regulate the pressure so it does not drop below 11 inches water

column at pressure tap.

•

If the problem persists and the refrigerator is still not working properly, contact your nearest Service Center. State the problem,

model, product- and serial-number. These details are stated on the data label inside the compartment.
